15060S 58kg Thrust Brushless DC Motor for Camera Drone Agriculture UAV AGV Heavy Lift Drone
Zero-G15060S motor is engineered for a range of applications including VTOL drones, heavy lift drones. Enhance your setup further by pairing it with the 45 inch propeller and 24S 200A motor controller, delivering a maximum thrust up to 58KG.
Application 1/2
Heavy lift drone
58KG
Max. Thrust
31N·m
Max. Torque
100% hand-winding wire with special coating layer, featuring temperature resistant, aging resistant and fireproof.
World-renowned bearing, ensuring trouble-free service over 1800 hours.
Curved magnet, it improve efficiency, dissipate heat effectively, and minimize vibration and noise.
0.2mm laminations, thinner laminations improve power density and lead to higher efficiency, smoother operation.
Application 1/2
Multi rotor drone
Application 2/2
Paraglider
Propulsion system
Main Specifications
Specs shown here are test results based on standard model, you are most welcome to contact us to customize a product that work the best for you.
ø154 x 60mm
72 / customized
58KG
31N·m
3588
24S 200A
45 inch
174A
89V
15KW
14S-24S
Optional
2.5KG
